• 2 Core Stranded Copper, XLPE Insulated, SWA, PVC Sheathed Cable
  • Specifically designed for Railway LV Power cables and contain all components to complete the joint.




Part

Reference



PADS No.


Conductor Size sqmm (CSA)

Connectors

GBK3001

054/212866

2 x 10

Inc. Crimp Connectors

GBK3001M

054/212867

2 x 10

Inc. Mechanical Connectors

GBK3002

054/212868

2 x 16

Inc. Crimp Connectors

GBK3002M

054/212869

2 x 16

Inc. Mechanical Connectors

GBK3003

054/212870

2 x 25

Inc. Crimp Connectors

GBK3003M

054/212871

2 x 25

Inc. Mechanical Connectors

GBK3004

054/212872

2 x 35

Inc. Crimp Connectors

GBK3004M

054/212873

2 x 35

Inc. Mechanical Connectors

GBK3005

054/212874

2 x 50

Inc. Crimp Connectors

GBK3005M

054/212875

2 x 50

Inc. Mechanical Connectors

GBK3006

054/212876

2 x 70

Inc. Crimp Connectors

GBK3006M

054/212877

2 x 70

Inc. Mechanical Connectors

GBK3007

054/212878

2 x 95

Inc. Crimp Connectors

GBK3007M

054/212879

2 x 95

Inc. Mechanical Connectors


Polymeric Cable - Armoured

  • 3 Core Stranded Copper, XLPE Insulated, SWA, PVC Sheathed Cable
  • Specifically designed for Railway LV Power cables and contain all components to complete the joint.

Part

Reference

PADS No.

Conductor Size sqmm (CSA)

Connectors

GBK3008

054/212880

3 x 10

Inc. Crimp Connectors

GBK3008M

054/212881

3 x 10

Inc. Mechanical Connectors

GBK3009

054/212882

3 x 16

Inc. Crimp Connectorsv

GBK3009M

054/212883

3 x 16

Inc. Mechanical Connectors

GBK3010

054/212884

3 x 25

Inc. Crimp Connectors

GBK3010M

054/212885

3 x 25

Inc. Mechanical Connectors

GBK3011

054/212886

3 x 35

Inc. Crimp Connectors

GBK3011M

054/212887

3 x 35

Inc. Mechanical Connectors

GBK3012

054/212888

3 x 50

Inc. Crimp Connectors

GBK3012M

054/212889

3 x 50

Inc. Mechanical Connectors

GBK3013

054/212890

3 x 70

Inc. Crimp Connectors

GBK3013M

054/212891

3 x 70

Inc. Mechanical Connectors

GBK3014

054/212892

3 x 95

Inc. Crimp Connectors

GBK3014M

054/212893

3 x 95

Inc. Mechanical Connectors



Polymeric Cable – Armoured

  • 2 Core Stranded Copper, XLPE Insulated, SWA, PVC Sheathed Cable
  • 2 Core Stranded Copper, PILC Insulated, Lead Covered, SWA, PVC Sheathed Cable
  • Specifically designed for Railway LV Power cables and contain all components to complete the joint.

Part

Reference

PADS No.

Conductor Size sqmm (CSA)

Connectors

GBK3023

054/212814

2 x 10

Inc. Crimp Connectors

GBK3023M

054/212815

2 x 10

Inc. Mechanical Connectors

GBK3024

054/212816

2 x 16

Inc. Crimp Connectors

GBK3024M

054/212817

2 x 16

Inc. Mechanical Connectors

GBK3025

054/212818

2 x 25

Inc. Crimp Connectors

GBK3025M

054/212819

2 x 25

Inc. Mechanical Connectors

GBK3026

054/212820

2 x 35

Inc. Crimp Connectors

GBK3026M

054/212821

2 x 35

Inc. Mechanical Connectors

GBK3027

054/212822

2 x 50

Inc. Crimp Connectors

GBK3027M

054/212823

2 x 50

Inc. Mechanical Connectors

GBK3028

054/212824

2 x 70

Inc. Crimp Connectors

GBK3028M

054/212825

2 x 70

Inc. Mechanical Connectors

GBK3029

054/212826

2 x 95

Inc. Crimp Connectors

GBK3029M

054/212827

2 x 95

Inc. Mechanical Connectors



Polymeric Cable – Armoured

  • 3 Core Stranded Copper, XLPE Insulated, SWA, PVC Sheathed Cable
  • 3 Core Stranded Copper, PILC Insulated, Lead Covered, SWA, PVC Sheathed Cable
  • Specifically designed for Railway LV Power cables and contain all components to complete the joint.

Part

Reference

PADS No.

Conductor Size sqmm (CSA)

Connectors

GBK3037

054/212828

3 x 10

Inc. Crimp Connectors

GBK3037M

054/212829

3 x 10

Inc. Mechanical Connectors

GBK3038

054/212830

3 x 16

Inc. Crimp Connectors

GBK3038M

054/212831

3 x 16

Inc. Mechanical Connectors

GBK3039

054/212832

3 x 25

Inc. Crimp Connectors

GBK3039M

054/212833

3 x 25

Inc. Mechanical Connectors

GBK3040

054/212834

3 x 35

Inc. Crimp Connectors

GBK3040M

054/212835

3 x 35

Inc. Mechanical Connectors

GBK3041

054/212836

3 x 50

Inc. Crimp Connectors

GBK3041M

054/212837

3 x 50

Inc. Mechanical Connectors

GBK3042

054/212838

3 x 70

Inc. Crimp Connectors

GBK3042M

054/212839

3 x 70

Inc. Mechanical Connectors

GBK3043

054/212840

3 x 95

Inc. Crimp Connectors

GBK3043M

054/212841

3 x 95

Inc. Mechanical Connectors


Polymeric Cable – Armoured

  • 2 Core Stranded Copper, PILC insulated, Lead Covered, SWA, PVC Sheathed Cable
  • Specifically designed for Railway LV Power cables and contain all components to complete the joint.

Part

Reference

PADS No.

Conductor Size sqmm (CSA)

Connectors

GBK3044

054/212842

2 x 10

Inc. Crimp Connectors

GBK3044M

054/212843

2 x 10

Inc. Mechanical Connectors

GBK3045

054/212844

2 x 16

Inc. Crimp Connectors

GBK3045M

054/212845

2 x 16

Inc. Mechanical Connectors

GBK3046

054/212846

2 x 25

Inc. Crimp Connectors

GBK3046M

054/212847

2 x 25

Inc. Mechanical Connectors

GBK3047

054/212848

2 x 35

Inc. Crimp Connectors

GBK3047M

054/212849

2 x 35

Inc. Mechanical Connectors

GBK3048

054/212850

2 x 50

Inc. Crimp Connectors

GBK3048M

054/212851

2 x 50

Inc. Mechanical Connectors


Polymeric Cable – Armoured

  • 3 Core Stranded Copper, PILC insulated, Lead Covered, SWA, PVC Sheathed Cable
  • Specifically designed for Railway LV Power cables and contain all components to complete the joint.



Part

Reference

PADS No.

Conductor Size sqmm (CSA)

Connectors

GBK3049

054/212852

3 x 10

Inc. Crimp Connectors

GBK3049M

054/212853

3 x 10

Inc. Mechanical Connectors

GBK3050

054/212854

3 x 16

Inc. Crimp Connectors

GBK3050M

054/212855

3 x 16

Inc. Mechanical Connectors

GBK3051

054/212856

3 x 25

Inc. Crimp Connectors

GBK3051M

054/212857

3 x 25

Inc. Mechanical Connectors

GBK3052

054/212858

3 x 35

Inc. Crimp Connectors

GBK3052M

054/212859

3 x 35

Inc. Mechanical Connectors

GBK3053

054/212860

3 x 50

Inc. Crimp Connectors

GBK3053M

054/212861

3 x 50

Inc. Mechanical Connectors

GBK3054

054/212862

3 x 70

Inc. Crimp Connectors

GBK3054M

054/212863

3 x 70

Inc. Mechanical Connectors

GBK3055

054/212864

3 x 95

Inc. Crimp Connectors

GBK3055M

054/212865

3 x 95

Inc. Mechanical Connectors


Polymeric Cable – Armoured

  • 4 Core Stranded Copper, XLPE Insulated, SWA, PVC Sheathed Cable.
  • Specifically designed for Railway LV Power cables and contain all components to complete the joint.



Part

Reference

PADS No.

Conductor Size sqmm (CSA)

Connectors

GBK3058

054/212800

4 x 10

Inc. Crimp Connectors

GBK3058M

054/212801

4 x 10

Inc. Mechanical Connectors

GBK3059

054/212802

4 x 16

Inc. Crimp Connectors

GBK3059M

054/212803

4 x 16

Inc. Mechanical Connectors

GBK3060

054/212804

4 x 25

Inc. Crimp Connectors

GBK3060M

054/212805

4 x 25

Inc. Mechanical Connectors

GBK3061

054/212806

4 x 35

Inc. Crimp Connectors

GBK3061M

054/212807

4 x 35

Inc. Mechanical Connectors

GBK3062

054/212808

4 x 50

Inc. Crimp Connectors

GBK3062M

054/212809

4 x 50

Inc. Mechanical Connectors

GBK3056

054/212810

4 x 70

Inc. Crimp Connectors

GBK3056M

054/212811

4 x 70

Inc. Mechanical Connectors

GBK3057

054/212812

4 x 95

Inc. Crimp Connectors

GBK3057M

054/212813

4 x 95

Inc. Mechanical Connectors



Polymeric Cable - Armoured

  • 2 & 3 Core Stranded Copper, XLPE Insulated, SWA, PVC Sheathed Cable.
  • Range Taking Kits
  • Specifically designed for Railway LV Power cables and contain all Network Rail approved (PA05/04775) components to complete the joint.
  • Each kit contains 3 mechanical connectors.

Part

Reference

PADS No.

Conductor Size sqmm (CSA)

Connectors

GBK3064M

TBC

2 or 3 x 1.5-6.0

Inc. Mechanical Connectors

GBK3065M

TBC

2 or 3 x 10.0-25.0

Inc. Mechanical Connectors

GBK3066M

TBC

2 or 3 35.0-70.0

Inc. Mechanical Connectors

GBK3067M

TBC

2 or 3 x 95.0-120.0

Inc. Mechanical Connectors
